VB603 Intelligent Digital Wireless Two-way Intercom Baby Monitor

Product information:

LCD size: 3.2"

Supported resolution: 220×176

Receiving sensitivity: -90dBm work

Current consumption: 150 mA

Battery: Lithium polymer/750mAh

Power supply: 5V/500mA DC



Camera：

Image sensor: CMOS

Total picture pixels: 320×240pxl

Low illumination: 0 Lux (when the infrared light is on)

Night vision distance: 15 feet (5 meters)

Viewing angle: 55°

Power supply: 5V/500mA DC

General

Transmission frequency: ISM2400~2483.5 MHz

Transmit power: 17dBm

Transmission distance: 160ft/50m indoor/850ft/260m outdoor, line of sight

Spread spectrum: AFH and TDMA

Modulation mode: GFSK

Tempurature of work: 14?122 degrees Fahrenheit /-10? +50 degrees Celsius


Features

l Worry-free portable monitoring

l Two-way (talk back)

l Temperature monitoring

l Built-in 8 lullabies in the camera

l Automatic night vision

l Safe, no interference, long-distance digital signal

l High contrast 3.2" color LCD monitor

l Long battery life (5 hours Vox mode)

Packing details:

1×3.2" receiving display

1 camera

2 x power adapter

1 x user manual

General

Transmission frequency: ISM2400~2483.5 MHz

Transmit power: 17dBm

Transmission distance: 160ft/50m indoor/850ft/260m outdoor, line of sight

Spread spectrum: AFH and TDMA

Modulation mode: GFSK

Tempurature of work: 14?122 degrees Fahrenheit /-10? +50 degrees Celsius
